The Manifold Ripper

HEDT machine I have build and tuned to run my packing computations.

CPU
AMD Threadripper 3970x
32 physical / 64 logical cores
base clock 3.7 GHz ⇒ CCD 0, CCD 2, CCD 3 @ 4350 MHz & CCD 1 @ 4325 MHz, 1.45 VID

Main memory

4x16GB DDR4 Hynix CJR rated 3600 MT/s with primary timings 16-19-19-39 => clocked @ 3666 MT/s with primary timings 16-19-19-36
4x16GB DDR4 Samsung B-die rated 3200 MT/s with primary timings 14-14-14-34 => clocked @ 3666 MT/s with primary timings 16-19-19-36

Motherboard
ASUS Prime TRX40-Pro

CPU Power phase constrol: full phase mode
CPU VRM Switching frequency: fixed @ 1000kHz
CPU Load-line calibration @ Level 2
CPU Current capability: 140%

SOC Power phase constrol: full phase mode
SOC VRM Switching frequency: fixed @ 400kHz
SOC Load-line calibration @ Level 3
SOC Current capability: 140%

DRAM Power phase constrol: full phase mode
DRAM VRM Switching frequency: fixed @ 300kHz

Graphics card
GIGABYTE RTX 3090 VISION OC

GPU: GA102 82 simultaneous multiprocessors/328 tensor cores
base clock 1395 MHz / boost clock 1755 => clocked @ MHz 1545 MHz / boost 1905 MHz

VRAM: 24GB GDDR6X
base clock 9752 MT/s => clocked @ 10848 MT/s

Storage
SAMSUNG 980 PRO PCIe 4.0 NVMe SSD 1TB

PSU
EVGA SuperNOVA 1200 P2, 80+ PLATINUM 1200W

CPU cooler
IceGiant ProSiphon Elite
replaced default fans with 4x Noctua NF-F12 industrial PPC-3000 PWM fans

Case
LIAN LI Lancool-II-Mesh-Performance
additional case fans: 3x Noctua NF-F12 industrial PPC-3000 PWM and 5x NF-A14 industrialPPC-3000 PWM

Snapshot of my usual workloads

HWiNFO pooling period was set to 50 milliseconds.





Some benchmarks

(Left) AIDA64 Memory benchamark and (right) Cinebench 20

Geekbench 5

Geekbench Processor Benchmark Chart: https://browser.geekbench.com/processor-benchmarks
Geekbench CUDA Benchmark Chart: https://browser.geekbench.com/cuda-benchmarks

3090 thermal pad mod

Replaced/Upgraded graphic card thermal pads and thermal paste.

Birdy num num

A bird made a nest on the access point connecting The Manifold Ripper to the home network.
